500 Automatic Plastic Thermoforming Machine

 500 Automatic Plastic Thermoforming Machine

Main features:
1. The machine is designed and manufactured by the standard of “GMP" in medical industry and "QS" in food industry.
2. This machine can do forming, punching and blanking at the same time to avoid the cross-contamination of product.
3. The forming heating plate can open and close automatically, also can delay to start, so as to control and lower the waste of the material during the production.
4. Easy to replace the mould, application to different specifications of products.
5. Design the mould according to customer’s requirements.
6. Applicable projects: the material of HIPS, PVC, PET, PS.

Machine details:
Main technical parameters:
Cutting Frequency 10-33(times/min)
Power 380v/220v/50HZ
Stroke adjustable range 30-350mm
Max. Forming Depth 50mm
Max. Forming Area 480×320mm
Motor Power 4kw
Consumption ≥0.3m3/min
Pressure 0.6--0.8mpa
Overall Dimensions 2760×950×1720mm
Weight 2000kg

Option for Customers:
Add outer cover (extra to pay)
